Genie 37220R Safe-T-Beam Sensor Kit | GSTB Photo Eyes, Replaces 35048R, 34094R

Genie 37220R Safe-T-Beam Safety Sensor Kit (GSTB, GSTB-BX, GSTB-R, STB-BL, 37334R) - Source + Receiver Photo Eyes with Brackets

SKU:

37220R

Availability:

In Stock

Description

Genuine Genie 37220R Safe-T-Beam safety sensor kit (model GSTB; dealer pack GSTB-BX, retail GSTB-R / STB-BL, also 37334R) — the source and receiver photo eye pair with brackets and hardware for every Genie and Overhead Door opener that uses Safe-T-Beam, which is all of them from 1995 on. When the red LED on the receiver eye blinks, the door reverses from the floor, or the opener lights flash and will not close, this is the fix. Replaces the 34094R, 35048R, 305048R and 37334R kits.

Before you order: a Safe-T-Beam that is knocked out of line, sitting in direct sun, or wired with a corroded splice gives the same symptoms as a dead one. Wipe the lenses, check that both LEDs are steady (green on the source, red on the receiver), and re-aim. If the red LED still blinks with the lenses clean and the wires sound, replace the pair — they are sold as a matched set for a reason.

Specifications

Part number	37220R (GSTB, GSTB-BX, GSTB-R, STB-BL, 37334R; UPC 050049017514). Replaces 34094R, 35048R, 35048R.S, 305048R
Kit contents	Source (green LED) and receiver (red LED) sensors, 2 mounting brackets, screws and hardware, instructions. Bell wire not included
Fits	Genie and Overhead Door openers with Safe-T-Beam, 1995 onward — screw drive, chain, belt, Excelerator, PMX, ChainMax, SilentMax, StealthDrive, Aladdin Connect models. Not the model 2040 / 2040L or pre-1995 three-pin units
Mounting	Door track or wall, 5–6 in above the floor
Wiring	Two-wire to the terminals on the motor head
Condition	Genuine Genie, new

Fits

Genie opener family	Category
Intellicode AC screw drive — PRO95, CM7600, CM8600	PRO95 / CM7600 / CM8600 parts
H4000, H6000, 2060L, 3060L, 2560, 3560	H4000 / H6000 / 2060L / 3060L parts
Excelerator and DC screw drive — 1022, 1024, 1042, 2022, 2024, 2042	1022 / 1024 / 2022 / 2024 parts
1028, 2028, 3022, 3042, 4022; 2035, 2055, 3035, 3055, 7035, 7055; 1035, 1055, 2036	1028 / 2028 / 3022 / 4022 parts · 2035 / 2055 / 3035 / 7055 parts
2562, 2564, 3062, 3064, 4062, 4064; 3164H, 4063, 4164; H8000, PRO99, CMD9900	2562 / 2564 / 3062 / 4064 parts · H8000 / PRO99 / CMD9900 parts
PMX300-IC, PMX500-IC, IC250 chain / belt; PMX700, PMX1200, GPS700IC, GPS1200IC	PMX300 / PMX500 / IC250 parts · PMX700 / PMX1200 parts
Chainglide PCG, GCG350, H2000, 1020L, 2020L; 2033, 3053, 3155, 7053, 7135, 7155	PCG / GCG350 / H2000 parts · 2033 / 3053 / 7053 / 7155 parts
Current Genie: ChainMax, SilentMax, StealthDrive, Aladdin Connect models, Overhead Door CodeDodger	Any Intellicode opener 1995 onward

Common questions

Can I replace just one eye?
Genie sells them as a pair and the pair is what we stock. A mismatched single eye from another kit generation is the usual cause of a "new sensor still blinking" call.

Which side is which?
The source (green LED) goes on one side, the receiver (red LED) on the other; either side of the door. Aim them at each other until the red LED is steady.

The opener flashes and will not close but the beams look fine.
Check the wire run for staples through the insulation and splices, then swap the pair. Sun on the receiver lens at certain hours will also do it — move the receiver to the shaded side.

Genie photo eyes and wall stations · GK2 keypad · G3T-BX remote · Genie remote controls

Not sure your Genie takes this kit? Send a photo of the old sensor and the motor head to parts@gatehousesupplies.com or call 866-965-5599. We would rather confirm it than have you order twice.
