LiftMaster Solar Gate Operators

DC Arm Type Swing Gate Operators
DC Slide Gate Operators
DC Swing Gate Operators

A solar gate opener is two things: a 12V DC operator and a solar charging kit sized to how much the gate runs. Every LiftMaster operator on this page is 12V DC and solar-ready, so you pick the operator for your gate first, then the panel and battery to match your daily cycles.

Solar suits gates with no mains power at the entrance — a long driveway, a field gate, a remote yard. Running a trench and conduit to the gate typically costs more than the whole solar kit. All of these operators also run on mains power if you have it.

Step 1 — Choose the Operator

Gate type Operator Capacity
Sliding gate RSL12UL Residential slide, 12V DC, battery backup included
Swing gate, single LA500PKGUL Residential linear swing, one leaf
Swing gate, double LA500PKGUL-Dual Residential linear swing, two leaves
Swing gate, heavier RSW12UL Residential swing, 12V DC, battery backup included

Step 2 — Size the Solar Kit

Pick by how many times the gate opens per day, not by gate size. More cycles means more battery.

Kit Battery Suits
20W7A 7 AH, 12V Light use — a handful of cycles a day, one household
20W33A 33 AH, 12V Regular use, or shaded and northern sites where charging is slower
Solar-3 64 watt panel High cycle counts, multiple daily users, or a heavy gate
When in doubt, size up. An undersized battery is the most common reason a solar gate stops working in winter — short days and cold both cut charging. The cost difference between the 7 AH and 33 AH kit is far less than a callout.

Batteries & Replacements

Part Description
A12330 33 AH 12V battery, single, upgraded
A12330SGLPK 33 AH 12V battery with harness
A12330pack Two 33 AH 12V batteries — doubles the reserve

Access Control & Remotes

Every one of these is battery powered or draws almost nothing, so they suit a solar installation.

Part Description
KPW250 Wireless keypad, 250 codes
KPW5 Wireless keypad, 5 codes, Security+ 2.0
877LM Wireless keypad
891LM Single-button remote, Security+ 2.0
L993M 3-button remote
L932M 2-button keychain remote
L992U 2-button universal remote
892LT 2-button visor learning remote
K107A0031 Replacement keys for KPW5 and KPW250
041-0494-000 Remote control visor clip

Loop Detectors & Mounting

Part Description
EMX D-TEK Low-power loop detector, 12–24V AC/DC — the right choice on solar, it barely draws
LOOPDETLM LiftMaster plug-in loop detector
MSEL Steel mounting stand for a concrete pad
Q103 Swivel arm assembly, K75-50292
Q103 uphill kit Uphill arm kit — for gates that open up a slope

Common Questions

Will it work through winter? Yes, with the right kit. Short days and cold reduce charging, so size the battery for your worst month, not your best. In northern states or a shaded entrance, go to the 33 AH kit or the 64 watt panel.

What if the sun does not come out for a week? The battery carries the gate. A 33 AH battery holds several days of normal residential cycles with no charge at all.

Can I add solar to an operator I already own? Only if it is a 12V DC unit. A 120V AC operator cannot run from these kits. Check the operator's label or call us.

Does it need a battery even with a panel? Yes. The panel charges the battery; the battery runs the gate. A panel alone cannot open a gate at night.

Parts & Support

You need Go to
Repair parts for an RSL12 or RSW12 LiftMaster gate operator parts
Repair parts for an LA500 LA500 parts
All gate operators Gate operators & accessories

Not Sure What You Need?

Tell us the gate type and weight, how far it travels, how many times a day it opens, and how much direct sun the entrance gets. Call (866) 965-5599 — we install these and will size the panel and battery properly rather than sell you a kit that fails in January.
