GTO PRO SW4000XLS / SW4200XLS Swing Gate Operator Parts
How to use this page. Parts for the GTO / Linear PRO 4000XLS are grouped by section below; within each section they are in part-number order. Click the part number to order. The Fits column shows every GTO operator we list the part under — most of these parts also fit the SW3000XLS / SW3200XLS. GTO does not publish exploded diagrams for these operators, so match by part number and description.
Not sure which part has failed? Call (866) 965-5599 and we will work it out with you before you order.
Rev Counter Boards, Wheels & Cups
| Part Number | Description | Fits | Price |
|---|
| R4884 | Magnetic Rev Counter Wheel [NOW R4880] | 3000XLS, 4000XLS | $76.61 |
| R4918 | Rev Counter Board - SW3000XLS, SW4000XLS | 3000XLS, 4000XLS | $78.59 |
| RVCTBD3040 | Rev Counter Board - SW3000, SW4000 | 2000XLS, 3000XLS, 4000XLS | $63.86 |
| RVCTBDXL | Rev Counter Board - SW3000XL, SW4000XL | 3000XLS, 4000XLS | $66.79 |
No longer available — listed so you can confirm the number; the description names the replacement where one exists.
| Part Number | Description | Fits |
|---|
| RVCCUP3040 | Rev Counter Cup | 3000XLS, 4000XLS |
| RVCCUPXL | Rev Counter Cup | 3000XLS, 4000XLS |
Control Boxes & Logic Boards
| Part Number | Description | Fits | Price |
|---|
| R5211 | Logic Control Board - SW2000XL, SW3000XL, SW3000XLS, SW4000XL, SW4000XLS, FM500 (Replaces R4211) | 3000XLS, 4000XLS | $561.06 |
| R5500 | Loaded Hinged Control box 3000/4000 XLS | 3000XLS, 4000XLS | $742.49 |
| R5501 | Empty Hinged Control box | 3000XLS, 4000XLS | $243.06 |
No longer available — listed so you can confirm the number; the description names the replacement where one exists.
| Part Number | Description | Fits |
|---|
| PRO3040CBOX | Loaded Control box 4000XLS series operators | 4000XLS |
| PRO3040CBOXASY | Empty Control box 4000XLS series operators | 4000XLS |
| R4211 | Logic Control Board | 2000XLS, 3000XLS, 4000XLS |
Complete Operators & Second-Arm Kits
| Part Number | Description | Fits | Price |
|---|
| MM571W | Mighty Mule Smart Gate Opener | — | $1,023.31 |
| PRO-SW4000XLS | Automatic Gate Opener, Single Arm | — | $1,474.90 |
| PRO-SW4200XLS | Second Operator Dual Gate | — | $1,044.53 |
Replacement Arms & Front End Assemblies
| Part Number | Description | Fits | Price |
|---|
| PRO4000ARMXLS | Replacement Arm | 4000XLS | $811.23 |
No longer available — listed so you can confirm the number; the description names the replacement where one exists.
| Part Number | Description | Fits |
|---|
| FEA40XLS | Assembly, Front End | 4000XLS |
Gear Motors, Transformers & Power Supplies
| Part Number | Description | Fits | Price |
|---|
| RB570 | Transformer | 2000XLS, 3000XLS, 4000XLS | $33.58 |
No longer available — listed so you can confirm the number; the description names the replacement where one exists.
| Part Number | Description | Fits |
|---|
| R4200XLS | Gear Motor | 3000XLS, 4000XLS |
Power Cables & Harnesses
| Part Number | Description | Fits | Price |
|---|
| PCK30406 | Power Cable, 6' w/Strain Relief | 3000XLS, 4000XLS | $64.20 |
| R4887 | Power Cable, 6' w/Strain Relief | 3000XLS, 4000XLS | $78.33 |
Brackets, Mounts & Hardware
| Part Number | Description | Fits | Price |
|---|
| H401P | Hardware Bag for Black Brackets | 4000XLS | $70.39 |
| HB100 | Silver bracket set w/ captured gate bracket | 2000XLS, 3000XLS, 4000XLS | $75.88 |
| HB301 | Black 3000XL/4000XL Bracket Set w/captured gate bracket | 3000XLS, 4000XLS | $110.20 |
| HB4000 | Bracket Set | 4000XLS | $206.20 |
| HBP4XL | Hardware Upgrade Kit | 4000XLS | $286.61 |
| R4KPTO | Bracket 12' Special Push-to-Open | 4000XLS | $121.22 |
| RP1011 | Mounting Hardware for the MM37X/57X Operators | 3000XLS, 4000XLS, Mighty Mule | $54.81 |
No longer available — listed so you can confirm the number; the description names the replacement where one exists.
| Part Number | Description | Fits |
|---|
| FTMT40 | Front Mount Black | 4000XLS |
| H301P | Hardware Bag for Black Brackets | 3000XLS, 4000XLS |
| R4885 | Black Front Mount | 4000XLS |
| R4KGATE | Gate Bracket | 2000XLS, 3000XLS, 4000XLS |
| R4KPIVOT | Bracket 10' 4000XL(S) Series | 4000XLS |
| R4KPOST | Post Bracket 4000XL(S) Series | 4000XLS |
| R4KSTOP | Positive Stop Plate Powder Coated Black | 3000XLS, 4000XLS |
Housing, Covers & Seals
| Part Number | Description | Fits | Price |
|---|
| R4708 | Black Scraper Seal kit | 2000XLS, 3000XLS, 4000XLS | $48.13 |
No longer available — listed so you can confirm the number; the description names the replacement where one exists.
| Part Number | Description | Fits |
|---|
| R4404 | Scraper Seal Kit Black | 2000XLS, 3000XLS, 4000XLS |
| R4414 | Aluminum Housing Kit | 3000XLS, 4000XLS |
