Chamberlain LW2000 & LW3500 Belt Drive Parts
Chamberlain LW2000 and LW3500 Replacement Parts
These are belt drive openers. Everything for them is on this page: the motor unit, the safety sensors, the door hardware, the wall control and the remote. The reference numbers below match the diagram.
Motor runs but the door does not move? On a belt drive that is almost always the gear and sprocket assembly at ref 02 — the nylon gear strips. Grease the worm before fitting the new one; running it dry is what strips the next.
1. Motor Unit
First part of number below corresponds to diagram number above:
| Ref | Part # | Description |
|---|---|---|
| — | 041A4371 | Belt cap retainer |
| 02 | 041A4885-5 | Gear and sprocket assembly |
| 03 | 041B4245-1 | Line cord, 6 ft |
| 04 | 041A5484 | End panel with all labels |
| 05 | 041C0279 | Light socket |
| 06 | K108D0079M | Light lens |
| 07 | K030B0532-1 | Capacitor |
| 08 | K012A0373 | Capacitor bracket |
| 09 | 041A3150 | Terminal block with screws |
| 10 | 041C4842 | Motor |
| 11 | 41A5525-4 | Cover — no longer available |
| 12 | 041A2818 | Limit switch drive and retainer |
| 13 | 041D3452 | Limit switch assembly |
| 14 | 041A2822-1 | Interrupter cup |
| 16 | 041AB050-2M | Receiver logic board assembly |
| 17 | 041C5499 | High voltage wire harness |
| 17a | 041C5500 | Low voltage wire harness |
| 18 | 041D0180-1 | End panel |
The 041AB050-2M is the current receiver logic board for these openers. Read the number printed on the board you are removing before ordering — if it is not this one, call (866) 965-5599 with it and we will confirm the right replacement.
Cover no longer available. The ref 11 cover (41A5525-4) is discontinued with no replacement. Every other part on this diagram is available.
2. Belt and Rail
Ordering a belt? The belt is sized to your door height, not your rail. Chamberlain built belt drives on two different rail types — square rail and T rail — and the belts are not interchangeable. Look at the rail section: if it is square, you need the 41A5250 family; if it is a T shape, the 41A5434 family. Use the Chamberlain belt and rail parts page to match yours, or call (866) 965-5599 and we will identify it with you.
| Ref | Part # | Description |
|---|---|---|
| — | K144C0056 | Cable idler pulley |
| — | 183A163 | Wear pads |
| — | 004A1008 | Master link kit |
A belt rarely fails on its own. Check the idler pulley and the wear pads while the rail is apart — worn pads let the trolley rock in the rail and will chew through a new belt in months.
3. Safety Sensors and Brackets
| Ref | Part # | Description |
|---|---|---|
| — | 041-0136 | Safety sensor eye kit — sending and receiving eyes, matched pair |
| — | 041-0365-000 | Sensor eyes and brackets — the complete set |
| — | 041-0155-000 | Safety sensor brackets, 2021 to present |
| — | 041A5281-1 | Sensor extension brackets |
| — | 041B0873 | Sunblocker bracket — stops sunlight false-tripping the eye |
| — | 041B4494-1 | 2 conductor bell wire, 26 ft |
The current 041-0136 eye kit replaces the older 41A5034 and fits Chamberlain and LiftMaster openers alike — both brands are built by the same manufacturer and share sensors. If your brackets are bent or missing too, the 041-0365-000 includes eyes and brackets together.
4. Door Hardware and Installation Parts
| Ref | Part # | Description |
|---|---|---|
| — | 041B0035B | Curved door arm |
| — | 4178B0034B | Straight door arm section |
| — | 041A8094 | Door arm kit — curved and straight sections together |
| — | 041A5047-1 | Door bracket with clevis pin and fastener |
| — | 041A5047-2 | Header bracket with clevis pin and fastener |
| — | 041A2828 | Emergency release rope and handle |
| — | 041A2770-17 | Installation hardware kit |
| — | L6950 | Multi purpose spray lube |
5. Remotes and Wall Controls
| Ref | Part # | Description |
|---|---|---|
| — | 041A5273-1 | Wall control panel |
| — | 373LM | 3 button remote control |
| — | 893MAX | 3 button visor remote — universal replacement |
| — | 10A20 | 3V CR2032 remote battery |
| — | 889LM | MyQ control panel |
The 893MAX is the universal replacement for older Chamberlain, LiftMaster and Craftsman remotes. Browse all Chamberlain remote controls.
