Genuine LiftMaster K001A6426-2 control board (also written K1A6426-2) — the main control board in the separate wall-mounted control box of the RSL12V / RSL12VH slide and RSW12V / RSW12VH swing gate operators, the 12 V chain-drive and linear-arm residential operators with a mechanical limit shaft. The same board serves all four.
V, not U. The RSL12V and RSW12V are not the RSL12U / RSW12U and share very little with them. The U models have the electronics built into the operator with an APS encoder; the V models have this board in a separate box. Read the model on the label and the number on the board.
Specifications
| Part number | K001A6426-2 (also K1A6426-2) |
|---|---|
| LiftMaster description | Control Board, RSL12V / RSW12V |
| Radio | Through the separate K001A6636 low-power 315 MHz RF board (the 390 MHz K001A6636-1 is no longer available) |
| Fits | RSL12V, RSL12VH, RSW12V, RSW12VH |
| Condition | Genuine LiftMaster OEM, new |
Which operators use it
| Operator | Parts page |
|---|---|
| RSL12V, RSL12VH slide gate | RSL12V parts |
| RSW12V, RSW12VH swing gate | RSW12V parts |
Two boards, two jobs. This board runs the operator. Remotes are received by the K001A6636 RF board; if the remotes fail but the wired controls work, that board or the antenna is the suspect, not this one. The RSW12V also has a separate K001A6407-1 absolute encoder logic board.
Parts often replaced with it
K001A6636 RF board · K204B0195-1 transformer · K001A6407-1 encoder logic board (RSW12V) · K76-35321 learn limit kit
Is the board actually the problem?
The logic board is the most over-ordered part on a commercial operator. Work down this list before you buy:
| Symptom | Check first |
|---|---|
| Operator dead, no board lights | The K204B0195-1 power supply and the battery before this board |
| Remotes do nothing, wired controls work | The RF board or antenna, not this board |
| Gate overruns or will not find its limits | Limit shaft and switches (RSL12V) or the encoder board (RSW12V) |
| Dead after a storm | This board — fit surge protection with it |
After fitting
Set the limits, learn the remotes through the RF board, and re-test the entrapment reversal and any loops or eyes before returning the gate to service.
Fit surge protection when you fit the board. Lightning and utility surges are the most common reason a commercial operator board is replaced, and a new board on the same unprotected supply is at the same risk. The MOV kit on the electrical box is the first line; a proper surge arrester on the supply is the second.
Related
RSL12V parts · RSW12V parts · all LiftMaster gate operator parts
Not sure which board you need? Send a photo of the number printed on your existing board to parts@gatehousesupplies.com or call 866-965-5599. We would rather confirm it than have you fit the wrong board.
