LiftMaster EL2000 Replacement Parts
Genuine LiftMaster replacement parts for the EL2000 telephone entry system — the multi-board entry unit with display, 16-button keypad, camera lens and postal lock. Use the exploded diagram above to find the key number for the part you need, then click any part number in the tables below.
Two part numbers are stocked under different codes. The LED board is filed as 2B721 and the bypass board as SN1600341-K. Both are the correct parts.
Four boards, four jobs. The main board (041B0735) runs the unit, the input board (041B0736) takes the keypad and call button, the output board (041B0737) drives the relays, and the interconnect board (041B0997) links the door to the enclosure.
The housings and faceplates are discontinued in all three finishes, as is the display window gasket. Where a part number appears without a link, LiftMaster no longer supplies it.
Ref 22 is the EL25 key. The same replacement key fits the EL25 and the EL2000 lock kit.
Common EL2000 Faults
| Symptom | Usual cause | Parts to check |
|---|---|---|
| Display blank or garbled | Display assembly or its cables | 041B0989 display and board, 041B0990 display cables kit |
| Keys unresponsive or intermittent | Keypad or input board | 041D0236 keypad, 041B0736 input board |
| Gate relay not firing on a valid code | Output board | 041B0737 output board |
| No audio, or visitor cannot be heard | Speaker or mic cable | 041B0639 speaker, 041B0692 mic cable |
| Erratic behaviour as the door is opened | Door interconnect cables | 041B0994 cables kit, 041B0997 interconnect board |
| Call button does nothing | Call button kit | 041B0995 call button kit |
| Water inside the enclosure | Keypad gasket perished | 041C0087 keypad gasket |
| Need to open the gate with phone line down | Bypass board not fitted or failed | SN1600341-K bypass board |
Entry System Repair & Service Parts
| Ref | Part # | Description |
|---|---|---|
| 1 | 041B0991 | Housing, Black — no longer available |
| 1 | 041B0992 | Housing, Gray — no longer available |
| 1 | 041B0993 | Housing, Nickel — no longer available |
| 2 | 041B0737 | Output Board |
| 3 | 041B0735 | Main Board |
| 4 | 041B0736 | Input Board |
| 5 | 041B0989 | Assembly, Display and Board |
| 6 | 041B0990 | Display Cables Kit |
| 7 | 041B0705 | Cable, 20 Pin |
| 8 | 041B0704 | Cable, 14 Pin |
| 9 | 041B1002 | Faceplate, No Window, Black |
| 9 | 041B1003 | Faceplate, No Window, Gray |
| 9 | 041B1004 | Faceplate, No Window, Nickel |
| 10 | 041B1000 | Gasket and Display Window, Clear |
| 10 | 041B1001 | Gasket and Display Window, Black |
| 11 | 041B0692 | Mic Cable |
| 12 | 041B0081-1 | Camera Lens, Clear |
| 13 | 041B0773-1 | LED Board — stocked as 2B721 |
| 14 | 041B0994 | Door Interconnect Cables Kit |
| 15 | 041B0998 | Entry LED Board — no longer available |
| 16 | 041C0087 | Keypad Gasket |
| 17 | 041D0236 | Keypad, 16 Button |
| 18 | 041B0996 | Postal Lock Switch Kit — no longer available |
| 19 | 041B0997 | Interconnect Board |
| 20 | 041B0639 | Speaker |
| 21 | 041B0999 | Lock and Key Kit |
| 22 | 041B0012 | Replacement Key, EL25 |
| 23 | 041B0995 | Call Button Kit |
Parts Not Shown in Diagram
| Ref | Part # | Description |
|---|---|---|
| — | 041B0747 | Direct Connect Cable |
| — | KSN1600341B | Bypass Board — stocked as SN1600341-K |
Accessories
| Ref | Part # | Description |
|---|---|---|
| — | KPR2000 | Wired Keypad and Proximity Reader |
| — | PPWR | Passport Receiver |
