Chamberlain RJO20 Replacement Parts
Genuine replacement parts and repair components for the Chamberlain RJO20, RJO20C and RJO20CH wall mount garage door opener. Use the diagram above and the part-number tables below to identify the exact component you need. Click any part number to view or order that part.
Garage Door Opener Repair Parts
| Ref | Part Number | Description |
|---|---|---|
| 1 | 041DJ002MC | Receiver Logic Board, RJO |
| 2 | 041B8861 | Travel Module with Wire Harness |
| 3 | 041C0168 | Transformer, 120V |
| 4 | 041A6095 | Motor Kit |
| 5 | 041B0122 | Power Cord Kit, RJO |
| 6 | 041A6348-3 | Cover, RJO |
Installation Parts
| Ref | Part Number | Description |
|---|---|---|
| 1 | 041A7928-3MC | MyQ Control Panel |
| 2 | 953EV-P2 | 3-Button Remote Control |
| 3 | K010A0020 | 3V CR2032 Lithium Battery |
| 4 | K029B0137 | Remote Control Visor Clip |
| 5 | 041A4582 | Rope and Handle Kit, RJO |
| 6 | 041B4494-1 | Bell Wire Kit |
| 7 | 041A6104 | Cable Tension Monitor Kit |
| 8 | 041B6228 | Mounting Bracket Kit, RJO |
| 9 | 041-0136 | Safety Sensor Kit |
| 10 | 041D8615 | Door Shaft Collar, RJO |
| 11 | 041A6102 | Power Door Lock Kit |
| 12 | 041-0155-000 | Safety Sensor Bracket Kit |
| 13 | 041A6287 | Wall/Ceiling Mount Remote Light |
| 14 | 041D0096-1 | Light Lens |
| — | 041A5281-1 | Safety Sensor Extension Bracket Kit |
| — | 041A6288 | Work Light Hardware Kit |
| — | 041A6298 | Installation Hardware Kit |
