LiftMaster CAPXM Smart Video Intercom – M
The LiftMaster CAPXM (LiftMaster part number CAPXMMC) is a cloud video entry system built for multi-family buildings of roughly 10 to 49 units, controlling up to two gates or doors from a single station. Residents see and speak with visitors on the 7" touchscreen or from their phone; property managers run resident turnover and access schedules from the myQ® Community web portal.
Key Features
- 7" 720p colour touchscreen, fade-resistant, with picture-in-picture directory navigation and customisable background
- 135° wide-angle camera at 1080p with night vision
- Controls 2 gates or doors — 2 Wiegand inputs, 4 relay outputs
- myQ® Community app (iOS and Android) — video calling, remote unlock, virtual guest passes, Siri support
- myQ mobile credentials, PIN and RFID entry options
- Cloud management portal for residents, schedules and tenant turnover
- Real-time alerts, configurable code-overuse and service notifications
- Two-factor authentication, ISO/IEC 27001:2013 compliant
- Ethernet or Wi-Fi connectivity
- Wireless link to UL 325 LiftMaster gate operators (firmware 4.2) — no trenching required
- GOOD DESIGN award winner
Specifications
| Display | 7" 720p high-definition touchscreen, picture-in-picture |
| Camera | 1080p, 135° field of view, night vision |
| Entrances controlled | 2 gates or doors |
| Inputs / outputs | 2 Wiegand inputs, 4 relay outputs |
| Designed for | Multi-family buildings of 10–49 units |
| Connectivity | Ethernet and Wi-Fi |
| Dimensions | 17"H x 6.125"W x 4"D |
Choosing Between the S, M and L
| Model | Screen | Entrances | Best Fit |
|---|---|---|---|
| CAPXS | 5" | 1 | Small buildings, gated homes |
| CAPXM | 7" | 2 | 10–49 unit buildings |
| CAPXLV2 | 10" | 4 | 50 to 50,000 units, high-rises |
Mounting and Accessories
- CAPXMTK — Trim Kit for flush mounting
- CAPXLCAM — USB camera kit (check compatibility for your build)
See all CAPXM parts and accessories →
Service Parts
- K41-0223-000 — Microphone Kit
- K41-0219-000 — Postal Lock Switch
- K41-0215-000 — Cam and Lock Kit
- K41-0227-000 — Power Supply Kit
Subscription
All LiftMaster Smart Access Solutions, including the CAPXM, require a monthly myQ Community subscription. Call us and we will size the plan, app licences and video storage to your property before you order.
