Genuine Linear HAE00040 control board — the combined logic, MegaCode receiver and torque control board for Linear's AC residential garage door openers: LDO33, LDO50, LSO50 and LCO75. It is the current replacement for the HAE00039 and the earlier HAE00003; the wiring and mounting are the same, so it goes straight into an opener that shipped with either. Receives Linear MegaCode 318 MHz remotes and keypads.
Put the opener on a surge protector when you fit the new board. Lightning and utility surges are the most common reason a garage door opener logic board is replaced, and a new board on the same unprotected outlet is at the same risk. A plug-in surge protector rated for motors is a small cost next to a second board.
Specifications
| Part number | HAE00040 (UPC 093863115912). Replaces HAE00039 and HAE00003 |
|---|---|
| Type | Control board — logic, receiver and force / torque control on one board, with end panel |
| Receiver | Linear MegaCode 318 MHz (MCT, MTS and ACT remotes, MDKP keypad) |
| Fits | Linear LDO33, LDO50, LSO50, LCO75 AC openers (our records also show it on the LCO50 — confirm by the number on your old board) |
| Not for | LDCO800 / LDCO801 DC openers — those take the HAE00077 (replaces HAE00061) |
| Condition | Genuine Linear, new |
Fits
| Opener | Board |
|---|---|
| Linear LDO33 | HAE00040 (was HAE00039 / HAE00003) |
| Linear LDO50 | HAE00040 (was HAE00039 / HAE00003) |
| Linear LSO50 / LSO50-2T1KB / LSO50-2T1KB8 | HAE00040 |
| Linear LCO75 | HAE00040 |
| Linear LCO50 | HAE00040 per our records — send a photo of the old board |
| Linear LDCO800 / LDCO801 | HAE00077 — not this board |
Is the board the problem?
The board is blamed for more than it causes. Work through this first:
| Symptom | Check first |
|---|---|
| Opener dead, no light, no response | Power first — outlet, then the transformer, then the board |
| Runs down, reverses at the floor | Force setting on the board, then the door balance and the photo eyes |
| Wall button works, remotes do not | The receiver half of this board, after checking the remote batteries and the antenna wire |
| Runs one way only | Often the board, but check the limits and the safety beams first |
| Buzzes but the door does not move | Stripped gears — HAE00047 gear kit, not the board |
Common questions
My old board says HAE00039. Is this the right one?
Yes. Linear superseded the HAE00039 with the HAE00040; same connectors, same mounting.
Do my remotes need reprogramming?
Yes — the codes live on the board. Press the learn button and re-learn each remote and keypad; five minutes.
What is the torque control?
The board sets the opening and closing force. Set it after the door is balanced, not before, or the opener will reverse on a heavy door.
Related
HAE00047 gear kit · HAE00077 board (LDCO800 / 801) · LDO33 parts · LDO50 parts · LSO50 parts · LCO75 parts · MegaCode remotes and keypads
Not sure which board you need? Send a photo of the number printed on your existing board to parts@gatehousesupplies.com or call 866-965-5599. We would rather confirm it than have you fit the wrong board.
