CSL24ULWK This CSL24UL includes the LMWEKITU wireless edge kit
24VDC High Traffic Commercial Slide Gate Operator ideal for most demanding slide gate environments.
Commercial Slide gate operator with battery backup system
Updated unit complies with new UL325 code revised Aug 2018
System now requires monitored secondary entrapment devices
the unit will include LMRRU safety photo eye and 5 ft safety edge for rear of gate
as well as 20 feet of drive chain
Suggest LMWEKITU sold separately if wireless edge connection is desired
***Can only be used on level sliding gate
MODEL CSL24ULWK The LiftMaster Elite Series model CSL24ULWK is engineered for a million cycles in high-cycle, heavy-duty applications. A Battery Backup System provides uninterrupted access when the power is out, and Security+ 2.0 technology virtually eliminates radio interference. It also features integrated MyQ technology and the industry's only standard wireless dual gate communication system. The CSL24ULWK is rated for gates 50 ft. long or 1,500 lbs. Battery Backup System provides uninterrupted access when the power is out Provides up to 7 days or 100 cycles on battery backup. Also powers safety and ancillary devices. Security+ 2.0 Technology Our patented Security+ 2.0 Technology provides two times the range of standard remote controls and virtually eliminates radio interference. An on-board radio receiver is included with the CSL24ULWK. It holds up to 50 remotes and is compatible with HomeLink version 4 and higher. Wireless dual gate communication prevents driveway scars and expensive wiring The on-board radio receiver provides a single remote control solution for gates and additional access points. It also features the industry's only standard wireless dual gate communication system that saves installation time and cost and eliminates unsightly scars from cutting driveways to run conduit for primary/secondary communication wiring. MODEL CSL24ULWK High-Traffic Commercial DC Slide Gate Operator with Battery Backup The LiftMaster Elite Series model CSL24ULWK is engineered for a million cycles in high-cycle, heavy-duty applications. A Battery Backup System provides uninterrupted access when the power is out, and Security+ 2.0 technology virtually eliminates radio interference. It also features integrated MyQ technology and the industry's only standard wireless dual gate communication system. The CSL24ULWK is rated for gates 50 ft. long or 1,500 lbs. Battery Backup System provides uninterrupted access when the power is out Provides up to 7 days or 100 cycles on battery backup. Also powers safety and ancillary devices. Security+ 2.0 Technology Our patented Security+ 2.0 Technology provides two times the range of standard remote controls and virtually eliminates radio interference. An on-board radio receiver is included with the CSL24ULWK. It holds up to 50 remotes and is compatible with HomeLink version 4 and higher. Wireless dual gate communication prevents driveway scars and expensive wiring The on-board radio receiver provides a single remote control solution for gates and additional access points. It also features the industry's only standard wireless dual gate communication system that saves installation time and cost and eliminates unsightly scars from cutting driveways to run conduit for primary/secondary communication wiring. Standard Features: Power Management System Supplies power when needed to operate the gate and conserves power when not in use Provides exceptional standby time and cycles on battery backup 7 days of standby time or 100 cycles on battery backup Fire department compliant: select able settings allow gate to auto-open upon loss of AC power or battery depletion Advanced traffic management control includes Quick-close and Anti-tailgating functions Bi-part delay: choose from Standard Operation or Synchronized Close Simple-to-set electronic limit system maintains accurate gate position throughout gate travel High-density, UV-resistant poly carbonate two-piece cover for excellent heat and corrosion resistance Programmable auxiliary relays Plug-in loop detectors External obstruction sensing;
Complies with 2018 UL325 safety codes
5-year commercial warranty
7-year residential warranty
Operators are to be installed by authorized Lift master technicians only.
Liftmaster CSL24U Installation Manual (click here)
Battery Backup
Secures and safeguards your property by providing up to 208 cycles or up to 24 days of standby power when the power is down.
Security+2.0
Access your property quickly with Security+2.0® Technology that utilizes a tri-band signal that virtually eliminates interference and offers extended range each time the remote control is used.
MyQ®
Securely control and monitor your Gate Operator from anywhere and get activity notifications through the MyQ® app.
P3 Motors
LiftMaster has designed its own purpose built motor to meet the exact requirements needed to open and close your gate.
Features:
LED DIAGNOSTIC DISPLAY Simplifies installation and troubleshooting.
SOLAR-READY ULTRA-RELIABLE SYSTEM Simple solar conversion delivers power when you need it most and is extremely power efficient at all other times to maximize solar performance.
PROGRAMMABLE AUXILIARY RELAYS Easily add additional features, such as warning lights/alarms.
POSILOCK® Automatically powers the operator and returns a gate to the closed position when gate is pushed off of closed limit.
PRE-MOTION WARNING ALARM Activates onboard alarm three seconds prior to gate motion.
ANTI-TAILGATE Prevents unauthorized access. Gate will pause when closing as vehicle pulls onto interrupt loop or breaks photo beam. Once
vehicle backs up, gate will continue to close.
QUICK CLOSE Closes the gate immediately after a vehicle pulls off the interrupt loop.
HOMELINK® COMPATIBLE Version 4 and higher.
SECURITY+ 2.0® ON-BOARD RADIO RECEIVER Up to 50 remote controls (unlimited with 811LM/813LM).
ENGINEERED FOR MORE THAN 1 MILLION CYCLES, OUR P3 Motor is designed to perform in the most demanding environments.
HEAVY-DUTY COMMERCIAL GEAR DRIVEN TRANSMISSION Provides unsurpassed reliability.
SOFT START/STOP extends operator and hardware life in high-cycle and heavy-gate applications.
WIRELESS DUAL-GATE COMMUNICATION Eliminates expensive conduit costs and unsightly driveway scars.
KEYED MANUAL DISCONNECT when unlocked allows gate to be operated manually.
FIRE DEPARTMENT COMPLIANCE allows gate to auto open upon loss of AC power or battery depletion
QUICK CLOSE/ANTI-TAILGATE quickly secures property, preventing unauthorized access.
SURGE SUPPRESSION provides industrial surge and lightning protection against strikes up to 50 feet away.
POWER 120V/230V Single Phase.
ACCESSORY POWER 24VDC 500mA output. Switched and unswitched power.
MONITORED SAFETY INPUTS 3 Main Board, 3 Expansion Board.
TEMPERATURE SPECIFICATIONS
Without Heater:
-4°F (-20°C) to 140°F (60°C).
With Optional Heater (HTR):
-40°F (-40°C) to 140°F (60°C).
UL USAGE CLASSIFICATION I, II, III, and IV.
GATE TRAVEL SPEED 12 in. per second.
Construction:
P3 MOTOR® 24VDC continuous-duty motor.
OPERATOR DUTY RATING High-cycle, high-temperature continuous duty.
CHASSIS Constructed with 1/4 in. gold zinc-plated steel for rust prevention.
WORM GEAR REDUCTION Commercial oil bath gearbox providing 10:1 worm gear reduction.
COVER High-density, UV-resistant polycarbonate 2-piece cover for excellent heat and corrosion resistance.
OPERATOR WEIGHT 140 lbs.
RECOMMENDED CAPACITIES Rated for gates up to 50 ft. in length or weighing up to 1,500 lbs.
CSL24UL Error Codes
00 Normal Operation No Action Required
31 Main control board has experienced an internal failure. Disconnect all power, wait 15 seconds, then reconnect power (reboot). If issue continues, replace main control board.
34 Absolute Position Encoder Error, not getting position information from encoder Check APE assembly and wiring connections. Replace the APE assembly if necessary.
35 Max-Run-Time Exceeded Error Check for an obstruction, then reprogram the limits.
36 Product ID Error Was the control board just replaced? If so, erase limits, enter limit setup mode and set limits. If not, disconnect all power, wait 15 seconds, then reconnect power before changing product ID harness.
37 Product ID Failure Unplug product ID harness then plug back in. Disconnect all power, wait 15 seconds, then reconnect power before replacing product ID harness.
38 Hard Stop Limit (Arm 1) Limit may be set too tightly against a non-resilient hard stop (re-adjust limit). Operator may be at end of travel (re-adjust mounting).
40 Battery overvoltage Too much voltage on the battery. Check harness. Make sure there is NOT a 24V battery on a 12V system.
41 Battery overcurrent Possible short of the battery charge harness. Check harness. Make sure you do NOT have a 12V battery on a 24V system.
42 No battery at boot up Check battery connections and installation. Replace batteries if depleted to less than 20V on a 24V system or less than 10V on a 12V system.
Make sure there is NOT a single 12V battery on a 24V system.
43 Exit Loop Error Failure or missing loop (SHORT or OPEN - LiftMaster Plug-in Loop Detector only) Check loop wiring throughout connection. May be a short in the loop, or an open connection in the loop.
44 Shadow Loop Error
45 Interrupt Loop Error
46 Wireless edge battery low Replace batteries in wireless edge.
50 Run-Distance Error The limits are less than the minimum requirement or longer than what was learned. Check limit positions and proper switch function. Run- distance can be re-learned by setting the handing again.
53 Brownout occurred AC/DC board supply dipped below allowable level. Review power supply and wiring. If rebooting, ensure enough time for discharge of power to force a fresh boot.
54 Wireless Second Operator Communication Error Check the second operator for power. If OFF, restore power and try to run the system. If powered, deactivate the wireless feature and then re-learn the second operator.
60 Minimum number of monitored entrapment protection devices not installed. Review monitored entrapment protection device connections. Slide gate operators require a minimum of two external safety devices; one in the close and one in the open direction.
61 CLOSE EYE/INTERRUPT held more than 3 minutes
Check wired input on main control board; check for alignment or obstruction.
62 CLOSE EDGE held more than 3 minutes
63 OPEN EYE/EDGE held more than 3 minutes
64 CLOSE EYE/INTERRUPT held more than 3 minutes Check wired input on expansion board; check for alignment or obstruction.
65 CLOSE EYE/EDGE held more than 3 minutes Check wired input on expansion board; check for alignment or obstruction.
66 OPEN EYE/EDGE held more than 3 minutes Check wired input on expansion board; check for alignment or obstruction.
67 Wireless edge triggered more than 3 minutes Check wired input for wiring issue or obstruction.
68 Wireless edge loss of monitoring Check wireless edge inputs.
69 Wireless edge triggered IF an obstruction occurred, no action required. If an obstruction did NOT occur, check inputs and wiring.
70 CLOSE EYE/INTERRUPT triggered, causing reversal, preventing close, or resetting TTC IF an obstruction occurred, no action required. If an obstruction did NOT occur, check alignment, inputs, and wiring on main control board
71 CLOSE EDGE triggered, causing reversal, NO preventing close, or canceling TTC
72 OPEN EYE/EDGE triggered, causing reversal or preventing opening
73 CLOSE EYE/INTERRUPT triggered, causing reversal, preventing close, or resetting TTC IF an obstruction occurred, no action required. If an obstruction did NOT occur, check alignment, inputs, and wiring on expansion board.
74 CLOSE EYE/EDGE triggered, causing reversal and preventing close or canceling TTC
75 OPEN EYE/EDGE triggered, causing reversal or preventing opening
80 Close input (EYE/EDGE) communication fault from other operator Check inputs and communication method between operators, either wired bus or radio. Ensure operator is powered. May have to erase the wireless communication and reprogram the two operators.
81 Open input (EYE/EDGE) communication fault from other operator
82 Close input (EYE/EDGE) communication fault (expansion board) Check the connections between the main board and the expansion board.
83 Open input (EYE/EDGE) communication fault (expansion board)
84 Non-monitored device detected on the wireless safety system Non-monitored contact closure devices are not supported. Make sure connected devices are monitored. Check edges for proper orientation and resistive end cap connection.
91 Force Reversal (Operator 1) Check for obstruction. If no obstruction, check that the mechanical assembly is engaged and free to move. See section on Limit and Force Adjustment, and Obstruction Test.
93 RPM / STALL Reversal (Operator 1) Check for obstruction. If no obstruction, check the operator wiring and that the mechanical assembly is engaged and free to move. Replace APE assembly.
99 Normal Operation No action required
