Linear 620-101293 APeX II Controller Module - Control Board for Linear PRO Access / OSCO Gate Operators

Linear 620-101293 — APeX II controller module assembly. The genuine replacement control board for Linear PRO Access (formerly OSCO) gate operators and barrier arms built on the APeX platform. One controller is shared across the slide, swing and barrier models, so this is the part to order when the APeX board in your enclosure has failed.

Backwards compatible. The APeX II drops into operators that shipped with the original APeX board; programming and wiring follow the same layout, so a technician who knows the APeX does not have to learn a new system. Motor board not included — this is the controller module only.

What is on the board

• Dual seven-segment LED display for programming and diagnostics — no DIP switches or potentiometers
• Built-in MegaCode radio receiver: stores up to 40 handheld transmitters and two MGT gate-edge transmitters
• Plug-in loop detector sockets for open, shadow/reset and reversing loops
• Integrated open / close / stop three-button station
• Networkable for dual-gate (master / slave) installations
• On-board low-voltage surge protection and auto-resetting fuses
• European-style plug-in field wiring connectors and LED status indicators
• Soft start / soft stop on DC battery-backup operators
• Works with standard 10K entrapment-protection devices; UL 325 (2016) compliant

Which operators use it?

The APeX controller family covers Linear’s HSLG, GSLG-A and VS-GSLG slide operators, the LRA swing operators and the matching barrier arms, among others. Confirm by looking at the board already fitted: an APeX or APeX II board has the two-digit LED display and the three-button station on the board itself. If your operator has an older board with DIP switches, send us the model number from the data plate and we will confirm the right part.

Not sure this is the right part? Send us the model number from your operator’s data plate and a photo of the part you are replacing — parts@gatehousesupplies.com or 866-965-5599. We would rather confirm it than have you order twice.
