PA1035 Keypad

The PA1035 keypad is designed to operate with Platinum Access control systems. This keypad is housed in a powder coated metal enclosure with a stainless steel front panel. The keys have bright, easy-to-read graphics. Each key has a tactile “click” feel when pressed. This keypad can be mounted to a pedestal, or directly to a wall. A key-Lock secures the keypad to the mounting plate. An incandescent panel lamp lights the Keypad for nighttime use. Red, green, and yellow indicator LED’s show power, access, and lockout conditions. The Keypad is powered by a 9-24 VDC power supply. It is also contains a backup battery to keep the keypad working when no AC power is available. Finally, this unit is manufactured with robust static, and lightning protection circuits, safeguard the electronic components.

Manual

Features and benefits:

Ultra Low Power Consumption

Multiple Power Supply Modes

Rechargeable

RF Remote Control

Hold Open Operation

Wireless and Wired Installation

Request to Exit Input

Adjustable Control Output Strike Duration

Additional information

Specification

Key code Range: 5-digi code: 0000-59999                            4- digi code: 0000-9999

Memory Capacity: 20,000 codes

Secure & Lock Case: Housed in a weather resistant metal box for outdoor installation.

Dimension: 4.5”X4”x8.25”H

Main Power: 9-24 VDC  power supply. Built-in Battery backup.

Optional Solar power.

Working temperature: -22°F to 140°F
