Doorking 6500 1/2 HP, 115 V (5.4) Secondary/Slave Swing Gate

(No reviews yet)
SKU:
6500-381
Availability:
In Stock

Product Price: $2,575.65
Condition:
New

*****DOES INCLUDE 6500-430 Arm assembly  ******

The 6500 series operators are designed to operate vehicular swing gates in residential, commercial and industrial applications for both single and bi-parting gates. The unique design of this operator allows for easy access to the electronics and mechanical areas of the operator without ever having to remove the gate arm. This simplifies installation and maintenance. The electronic magnetic limits will never wear out or break and they are easily adjusted. The solid steel frame and belt driven gear box make this operator one of the quietest on the market today. These operators can be equipped with a factory installed DC Convenience Open option which will automatically open the gate in the event of a power outage.

Click here for programming instructions.


Adjustable, no maintenance magnetic limits.
Overlap feature for bi-parting swing gate operation.
Simple connection for secondary operator in bi-parting applications.
Selectable shadow/reverse loop function.
Magnetic lock power provided. Ports for plug-in loop detectors.
Three 115 VAC convenience outlets. DC Powered convenience open (optional).
Gate tracker reporting output.
Programming switches.
Built-in reset switch. Built-in power On/Off switch.
Maximum gate width 18-ft. (1/2 HP) or 22-ft. (1 HP).
Maximum gate weight 700 pounds* (1/2 HP) or 800 pounds* (1 HP). (*Assumes gate swings level and is in good condition with properly adjusted hardware. Other external factors may affect the performance of the gate operator.)
Swings gate 90 degrees in approximately 12-14 seconds. 1/2 or 1 HP continuous-duty motor.
115, 230*, 460* VAC. (*230 and 460 volt units use a step-down power transformer to achieve 115 volt operating voltage.) Class I, II, III and IV applications.
Compliant with UL 325 and 991. ETL Listed. (Note: To be compliant with UL 325 and industry safety guidelines, additional secondary entrapment prevention devices are required to be installed with this gate operator. Your professional DKS system installer can provide you with more details on these devices and on current industry safety standards.)
Dimensions: 18.38"W x 31.63"H x 23.25"D

The Doorking 6500 1/2 HP Secondary/Slave Swing Gate Operator is engineered to provide efficient and reliable control for vehicular swing gates, suitable for residential, commercial, and industrial environments. This model, complete with the 6500-430 arm assembly, stands out in its category thanks to its user-friendly design, allowing easy access to both electronic and mechanical components without the need for removing the gate arm. This feature vastly simplifies installation and routine maintenance.

Durability and quiet operation are assured with the strong solid steel frame and a belt-driven gearbox, setting it apart as one of the market's quietest options. The built-in electronic magnetic limits not only offer adjustable settings but are also designed to last without wear, ensuring a maintenance-free operation over time. For added versatility, the unit supports a factory-installed DC Convenience Open feature, enabling automatic gate opening during power outages.

The Doorking 6500 comes equipped with a variety of advanced functionalities, including an overlap feature for bi-parting gates, adjustable magnetic limits, and selectable shadow/reverse loop functions. Ease of integration is further enhanced by simple connections for secondary operators, as well as magnetic lock power ports for plug-in loop detectors.

With a maximum gate width of 18 feet (1/2 HP) and a weight capacity of 700 pounds, this operator handles substantial gates with ease. Its powerful continuous-duty motor swings gates up to 90 degrees in approximately 12-14 seconds, ensuring efficient access. Compliance with UL 325 and 991 standards further guarantees safety, making this operator an ideal choice for various applications. Dimensions of the unit are 18.38"W x 31.63"H x 23.25"D, making it a compact solution for effective gate operation.
