CSL24UL Commercial Slide Gate Operator with Battery Backup [CSL24ULMC]

 New Liftmaster CSL24UL (replaces older model CSL24VDC and CSL24U)

Commercial Slide gate operator with battery backup system

Updated unit complies with new UL325 code revised Aug 2018
System now requires monitored secondary entrapment devices
The unit will include LMRRU safety photo eye and 5 ft safety edge for rear of gate
as well as 25 feet of drive chain. Exit loops not included and are sold separately.

All remotes and keypads are sold separately and located on page 52 in the manual.

 Suggest LMWEKITU sold separately if wireless edge connection is desired

***Can only be used on level sliding gate

MODEL CSL24UL The LiftMaster Elite Series model CSL24UL is engineered for a million cycles in high-cycle, heavy-duty applications. A Battery Backup System provides uninterrupted access when the power is out, and Security+ 2.0 technology virtually eliminates radio interference. It also features integrated MyQ technology and the industry's only standard wireless dual gate communication system. The CSL24UL is rated for gates 50 ft. long or 1,500 lbs. Battery Backup System provides uninterrupted access when the power is out Provides up to 7 days or 100 cycles on battery backup. Also powers safety and ancillary devices. Security+ 2.0 Technology Our patented Security+ 2.0 Technology provides two times the range of standard remote controls and virtually eliminates radio interference. An on-board radio receiver is included with the CSL24UL. It holds up to 50 remotes and is compatible with HomeLink version 4 and higher. Wireless dual gate communication prevents driveway scars and expensive wiring The on-board radio receiver provides a single remote control solution for gates and additional access points. It also features the industry's only standard wireless dual gate communication system that saves installation time and cost and eliminates unsightly scars from cutting driveways to run conduit for primary/secondary communication wiring. MODEL CSL24UL High-Traffic Commercial DC Slide Gate Operator with Battery Backup The LiftMaster Elite Series model CSL24UL is engineered for a million cycles in high-cycle, heavy-duty applications. A Battery Backup System provides uninterrupted access when the power is out, and Security+ 2.0 technology virtually eliminates radio interference. It also features integrated MyQ technology and the industry's only standard wireless dual gate communication system. The CSL24UL is rated for gates 50 ft. long or 1,500 lbs. Battery Backup System provides uninterrupted access when the power is out Provides up to 7 days or 100 cycles on battery backup. Also powers safety and ancillary devices. Security+ 2.0 Technology Our patented Security+ 2.0 Technology provides two times the range of standard remote controls and virtually eliminates radio interference. An on-board radio receiver is included with the CSL24UL. It holds up to 50 remotes and is compatible with HomeLink version 4 and higher. Wireless dual gate communication prevents driveway scars and expensive wiring The on-board radio receiver provides a single remote control solution for gates and additional access points. It also features the industry's only standard wireless dual gate communication system that saves installation time and cost and eliminates unsightly scars from cutting driveways to run conduit for primary/secondary communication wiring. Standard Features: Power Management System Supplies power when needed to operate the gate and conserves power when not in use Provides exceptional standby time and cycles on battery backup 7 days of standby time or 100 cycles on battery backup
5-year commercial warranty
7-year residential warranty
Operators are to be installed by authorized Lift master technicians only.

Liftmaster CSL24U Installation Manual (click here)

CSL24UL Data Sheet (click here)

The LiftMaster CSL24UL Commercial Slide Gate Operator with Battery Backup [CSL24ULMC] is a top-of-the-line solution designed for demanding commercial applications. Engineered for high performance, this advanced gate operator is built to withstand a million cycles, ensuring long-lasting reliability in heavy-duty environments. With a robust design that accommodates gates up to 50 feet long and weighing up to 1,500 pounds, the CSL24UL is ideal for a variety of commercial settings.

One of the standout features of the CSL24UL is its Battery Backup System, which guarantees uninterrupted gate access during power outages, providing up to 7 days or 100 cycles of operation. This system also supports safety devices, enhancing the protection of your property and ensuring smooth, secure entry for authorized personnel.

Safety is paramount with the CSL24UL, which complies with updated UL325 codes, including the requirement for monitored secondary entrapment devices. It comes equipped with essential safety components such as the LMRRU photo eye and a 5-foot safety edge, promoting a secure operation that minimizes risks.

With integrated MyQ technology, users can conveniently control and monitor their gate operator from anywhere, receiving activity notifications directly through the MyQ app. The patented Security+ 2.0 technology enhances user convenience by providing greater remote control range and virtually eliminating radio interference, which is crucial for seamless operation in busy environments.

Installation is worry-free thanks to the industry's only standard wireless dual gate communication system, simplifying setup and avoiding unsightly driveway modifications. For true accessibility, remotes and keypads are sold separately, allowing users to customize their access solutions.

Choose the LiftMaster CSL24UL for unmatched durability, reliability, and advanced safety features, ensuring your commercial property remains secure and accessible.

CSL24UL Error Codes

00 Normal Operation No Action Required
31 Main control board has experienced an internal failure. Disconnect all power, wait 15 seconds, then reconnect power (reboot). If issue continues, replace main control board.
34 Absolute Position Encoder Error, not getting position information from encoder Check APE assembly and wiring connections. Replace the APE assembly if necessary.
35 Max-Run-Time Exceeded Error Check for an obstruction, then reprogram the limits.
36 Product ID Error Was the control board just replaced? If so, erase limits, enter limit setup mode and set limits. If not, disconnect all power, wait 15 seconds, then reconnect power before changing product ID harness.
37 Product ID Failure Unplug product ID harness then plug back in. Disconnect all power, wait 15 seconds, then reconnect power before replacing product ID harness.
38 Hard Stop Limit (Arm 1) Limit may be set too tightly against a non-resilient hard stop (re-adjust limit). Operator may be at end of travel (re-adjust mounting).
40 Battery overvoltage Too much voltage on the battery. Check harness. Make sure there is NOT a 24V battery on a 12V system.
41 Battery overcurrent Possible short of the battery charge harness. Check harness. Make sure you do NOT have a 12V battery on a 24V system.
42 No battery at boot up Check battery connections and installation. Replace batteries if depleted to less than 20V on a 24V system or less than 10V on a 12V system.
Make sure there is NOT a single 12V battery on a 24V system.
43 Exit Loop Error Failure or missing loop (SHORT or OPEN - LiftMaster Plug-in Loop Detector only) Check loop wiring throughout connection. May be a short in the loop, or an open connection in the loop.
44 Shadow Loop Error
45 Interrupt Loop Error
46 Wireless edge battery low Replace batteries in wireless edge.
50 Run-Distance Error The limits are less than the minimum requirement or longer than what was learned. Check limit positions and proper switch function. Run- distance can be re-learned by setting the handing again.

53 Brownout occurred AC/DC board supply dipped below allowable level. Review power supply and wiring. If rebooting, ensure enough time for discharge of power to force a fresh boot.

54 Wireless Second Operator Communication Error Check the second operator for power. If OFF, restore power and try to run the system. If powered, deactivate the wireless feature and then re-learn the second operator.

60 Minimum number of monitored entrapment protection devices not installed. Review monitored entrapment protection device connections. Slide gate operators require a minimum of two external safety devices; one in the close and one in the open direction.
61 CLOSE EYE/INTERRUPT held more than 3 minutes
Check wired input on main control board; check for alignment or obstruction.
62 CLOSE EDGE held more than 3 minutes
63 OPEN EYE/EDGE held more than 3 minutes
64 CLOSE EYE/INTERRUPT held more than 3 minutes Check wired input on expansion board; check for alignment or obstruction.

65 CLOSE EYE/EDGE held more than 3 minutes  Check wired input on expansion board; check for alignment or obstruction.
66 OPEN EYE/EDGE held more than 3 minutes  Check wired input on expansion board; check for alignment or obstruction.

67 Wireless edge triggered more than 3 minutes Check wired input for wiring issue or obstruction.
68 Wireless edge loss of monitoring Check wireless edge inputs.
69 Wireless edge triggered IF an obstruction occurred, no action required. If an obstruction did NOT occur, check inputs and wiring.
70 CLOSE EYE/INTERRUPT triggered, causing reversal, preventing close, or resetting TTC IF an obstruction occurred, no action required. If an obstruction did NOT occur, check alignment, inputs, and wiring on main control board

71 CLOSE EDGE triggered, causing reversal, NO preventing close, or canceling TTC
72 OPEN EYE/EDGE triggered, causing reversal or preventing opening
73 CLOSE EYE/INTERRUPT triggered, causing reversal, preventing close, or resetting TTC  IF an obstruction occurred, no action required. If an obstruction did NOT occur, check alignment, inputs, and wiring on expansion board.

74 CLOSE EYE/EDGE triggered, causing reversal and preventing close or canceling TTC
75 OPEN EYE/EDGE triggered, causing reversal or preventing opening
80 Close input (EYE/EDGE) communication fault from other operator Check inputs and communication method between operators, either wired bus or radio. Ensure operator is powered. May have to erase the wireless communication and reprogram the two operators.
81 Open input (EYE/EDGE) communication fault from other operator
82 Close input (EYE/EDGE) communication fault (expansion board) Check the connections between the main board and the expansion board.
83 Open input (EYE/EDGE) communication fault (expansion board)

84 Non-monitored device detected on the wireless safety system Non-monitored contact closure devices are not supported. Make sure connected devices are monitored. Check edges for proper orientation and resistive end cap connection.

91 Force Reversal (Operator 1) Check for obstruction. If no obstruction, check that the mechanical assembly is engaged and free to move. See section on Limit and Force Adjustment, and Obstruction Test.

93 RPM / STALL Reversal (Operator 1) Check for obstruction. If no obstruction, check the operator wiring and that the mechanical assembly is engaged and free to move. Replace APE assembly.
99 Normal Operation No action required
