This residential and heavy-duty commercial swing gate operator is equipped with a powerful, quiet, brushless DC motor and operates on 24 volt DC power. In addition, this gate operator is built with a long-lasting, 7Ah 24V DC battery backup system that keeps the gate operational when AC power is unavailable.
The BLSW1016 is the first choice in heavy-duty commercial swing gate applications because of its many features. First, this full feature state-of-the-art operator uses a 120/220V AC single-phase main power source and a unique maintenance-free, brushless DC motor. The 120/220V AC power source is connected to a high-efficiency, switching power supply, which then provides the proper stable voltage to operate the gate operator.
Since the DC motor is brushless, there is no need to replace any brushes; whereas the brushed DC motor will eventually require brush replacement. The brushless DC motor is quiet, powerful, and designed to last up to 10 times longer than the conventional brushless DC motor. Moreover, the brushless DC motor’s typical life expectancy is between 10,000 and 20,000 working hours, compared to the conventional brushed DC motor’s 2,000 to 5,000 working hours, which is significant in terms of life expectancy due to the quality and design of our product.
Swing Gate Operator-Brushless 1000 lbs. 16' / 1400 lbs. 12'
Solar Panel Connectivity
This BLSW1016 model can operate with a direct solar panel connection, as an optional addition.
Battery Backup
The operator is also equipped with a built-in, powerful 24V DC battery backup system that uses two 12V, 7Ah lead acid batteries. With this, there is more than enough power to keep the gate operational until AC power is available again.
Operating Conditions
This operator is designed to operate in any climate:
1) it does not require a gearbox or a battery heater to operate in temperatures’ up to –20°F
2) temperatures –20°F and –40°F require a battery heater, and
3) below –40°F requires a gear box and battery heater.
These unique engineering innovations are backed by the safety and reliability of the most advanced control board in the industry to ensure a smooth operation for any Platinum Access
Systems operator.
Features and Benefits:
Continuous duty
Maximum gate width: 16 ft
Maximum gate weight: 1000 lbs
Heavy duty gearbox size: 70
Dynamic Speed Control – No speed variation when gate load changes and power switches between AC and battery.
Automatically Learning with Self-Synchronization – Automatically synchronizes gates with different travel times for primary/secondary gate installation.
Solar Priority Power Supply – With a larger solar panel, the gate will run on the solar panel instead of the batteries when the sun light is sufficient, thus increasing the life of the battery usage.
Soft Start and Soft Stop – Minimizes wear and tear on the gate system for an increased gate system life usage.
High Efficiency, Powerful, and Brushless Motor – Provides a smooth, high torque and maintenance free operation.
Solid State Motor Drivers – Provides a quietness and longer product life cycle.
Advanced Maglock Control – Engages the maglock before or after the gate is closed. Maglock works at both gate opening and closing position.
Dual Output Loop Detector Rack – Type “B” relays on the loop detector can be used for additional features.
Individual Alarm For Primary/Secondary Installation – Provides an alarm to indicates that the gate has encountered an obstruction of some sort.
Motor Brake and Maglock Release by FIRE/KEY input – Enables manual gate operation during an emergency.
One Controlled Power Supply Output for Photo Beam Detector – With a solar panel component installed with the unit, the unit can turn off the PBD when the gate is closed to increase the battery life usage.
High Capacity DC Back-Up – Over 100 cycles on DC back up depending on the model and gate size.
Adjustable Leaf Delay – on either leaf from the primary unit in the primary/secondary system.
Stackable Limit Switches – For additional features.
Fail Safe/Secure Capability – Ability to set fail secure, fail safe, or open on fail.
Heavy Duty Steel Chassis – Corrosion resistant powder coated chassis.
BLGOC-2200 control board with built-in input/output LED’s.
Electronic reversing sensor has been built into the control board
Adjustable timer - operates from 0-60 seconds.
Power Surge protection
Alarm reset button
Motor breaker
Loop rack board
AC power switch. Selectable 120VAC/220VAC power input source.
110V AC output outlet
Weatherproof polyethylene shell cover.
Working temperature is between -20°F to +158°F
Residential motor warranty: 10 years
Residential parts warranty: 8 years
Commercial motor warranty: 8 years
Commercial parts warranty: 6 years
Idler pulley warranty: 3 years
Battery (as the main power source)warranty: 2 year
Battery (used as a backup to the main solar panel power source) warranty: 6 months
