Linear AK-11 Linear Digital Keypad ACP00748 (replaces ak-1)



Up to 480 entry codes, from 1 to 6 digits in length, can be programmed. They can activate either, or both, of the relay outputs. Features Self-contained keyless entry system ideal for airports, hospitals, warehouses, office buildings, parking lots, and many other commercial facilities Rugged, cast aluminum enclosure for indoor or outdoor mounting on a wall or pedestal Four independent outputs and timers: two form C relays and two solid-state open collector outputs Up to 480 programmable input codes of one to six digits each for activating either or both relays Two LED indicators show system status Key operating features include: door sense input; inhibit input; request-to-exit input; alarm shunt output; timed anti-passback; and keypad lockout Down light illuminates whenever keypad is used Tactile and audible feedback Keylock secures keypad to mounting backplate 4" W x 5.5" H x 3" D
